Most of the weapons featured on this site already exist, the design brief is for defence units to save U.N. and NATO troops lives in the war zones deployed. A rule of thumb guess is for every soldier saved they save 10 civilians.
This is the concept development page of the site, establishing the brief for construction of various units, the main one's being the Centurion and Pill box defence units. Said defence units evolved from my 'Hex Desks' concept, explained in part below, or for the full story go to www.hexdesks.com .
I hope that the diversity and variety that evolves with several groups prototyping, competing with designs that a finalized unit will evolve. The ultimate goal is a standardised base unit formats featuring the best aspects of all prototypes in to one finalized design, being a standardised Hex Desk base unit with interchangeable assembly modifications to be offered in the finalized product range.
The market segment for the two main designs 'Centurion' and 'Pill box' defence units is, for example, situations with under developed countries like in Africa where the top gun is the AK-47, not much in the line of rockets and poor infrastructure for motorized vehicles. The Pill box is essentially an assault rifle proof armored Hex Desk with a turret and machine gun ports. Materials utilized include titanium, composite armor and bullet proof mirror glass. Simplicity and ruggedness are key, the unit could fill this type of gap in the market well. The unit is also suitable for both automation and manned versions primarily for defending locations, but also for building to building clearance with the Pill box mini..
email :eddycrowley71@gmail.com
Please like my Face Book page and leave feedback :https://www.facebook.com/ulsterarms
Mission statement (first draft).
Ulster Arms ltd. Head Quarters and short, medium, long term goals.
Below: Concept development of Centurion and Pill box units.
Developed from the Hex desks concept and evolved for use as defence units for use at check points, boarder crossings etc. to be built in Ulster for the defence industry, especially the global export market, to exploit gaps in the market for both state and business security options.
Blue prints : Pill box defence unit; Prototype design.
Above; either mirror clad for the basic one, or TV flat screens showing camera image shot from the other side
giving the Pill box near invisibility cloaking.
Hex desk base unit on which defence units are based :
New blue prints; manufacture of component parts and assembly plan of Hex Desks base unit, on
which the Pill box is based. Tubular self assemble kit form. Prototype design.
Below : Plate sheet steel factory build prototype design.
Stronger than tubular butterfly screw assembly above but not able to disassemble and less easy to transport by vehicle.
This design of Hex desk is stack able for both storage and transporting in large numbers.
First draft of Centurion Defence Unit.
The next set of pages show the evolution of Hex desks to the Ulster Arms ltd. defence units
The Centurion and The Pill Box.
The ideal is to help get Ulster back on it's feet with an industrial evolution of product for the export market.
Lesser evil and better good is the motto.
Kit form or built to order defence units by Ulster Arms ltd.
Film story board featuring UA defence units
Fire fighting unit called ' The Fire Mum ' , she looks out for you.
Blade runners:
The roboroo:
Below is 'Freight box shuttle' an idea for Shorts of N.I.
Below is Ulster Arms 'Sun Harvester'.
The Night Hawk.
Drones:
Below, got the idea from watching 'Terminator Salvation' with the drone chasing the jeep.
Below, I think I got the idea from watching 'The 5th Element', Gary Oldman showing the aliens an assault rifle where all the bullets flew to the original target.. I thought mmmbh wabo 'The Mosquito' ouch !
Or was it that Angelina Jolie film 'Wanted' of shooting a bullet round in a circle and stuff.
Smoke and mirrors
Below is photo collage mock up of basic digger hub as armored manned, or automated for rescue tasking, Fetch Units .
My work is conceptual, ball park guesstimate for engineers to print and draw on, then blue print own solutions,
Base of steel table knife first into wine bottle then a quick shake up and down takes the bottom round off,
memory from film of British officer showing French resistance tactics in 1940's.
'I learned it all from TV and films in the public domain, I'm a bipolar dyslexic, who as a documenting cataloguer
with over 25 years portfolio think some of these ideas just might be useful for defenders in Ukraine'.
Glimirror (Urban Dazzler Cammo) for rubber neck, arms, cuffs waterproof reversible green or white survival suit.
First draft update on above:
Wheelie bin survival box conversions called 'Trench Trunk' ?
Mk. 2 (useful in Ukraine ?)
Time for Twin Zeppelin Red Cross accepted in area as mobile hospital ?
Loads of Civilian kit for Military adaptation, this just from memory.
Ripsaw from civi to military spec might fit the bill ?
A-10 Plane: GAU-8/A Avenger gun on Ripsaw ;
The M1917 Light Tank shows an old idea :
Just googled 'off road tracked vehicles' all of which could be adapted for non-civilian use as horse and carts up,
a backbone of supply and general purpose in European theatre of war, WW II and Cold war too. Cheap,
rugged, light, reliable proven kit, stick in a fleet of USA under belly gun Harriers, them in their natural field of play.
Snow ski's Army spec, WW I biplane front machine gun mounts & options :
Harrier options :
Star wars X - wing MK. 5 ?
A Harrier engine adaptation that might be useful in the Ukraine :
Reply from 2000AD, I asked for a lucky bag.
President Putin please watch Dr. Strangelove Dr. Strangelove - Wikipedia
Back to site propper:
Mon 30th Aug. 21'
Having resolved the major build issues by adapting the Centurion design to be fitted to machines already in production,
in this case a Centurion unit, based on a mini JCB digger, built to order, stripped to engine, rotating chassis and tracks,
then the cut off hex pyramid shell is welded in.
This solution massively reduces development costs and the mechanicals are robust, reliable and proven.
Artist's impression of JCB mini digger cut back to all that is required direct from assembly line at JCB to Belfast,
non-civilian Government developers.
Mini digger base unit conversion.
Park it in the trunk.
Please like my Face Book page and leave feedback :https://www.facebook.com/ulsterarms
Thank you for visiting the site, I hope you enjoyed the content, any comments welcome.
